Insulated Sandwich Panel Wall Panel Roof Panel

Durable Insulated Sandwich Panels for Walls and Roofs at our factory. Customized solutions for your construction needs. Contact us today!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
panel sandwich 30mm
Exterior Steel Thickness
0.4-0.8mm
Core Material
EPS/PU/PIR/PUR/Rock Wool/Glass Wool
Density
12/14/16/40/80/100/120 Kg/M3
Length
Customized, <11.9m
Width
950, 980, 1000, 1130, 1150mm
Lead Time
7-15 Days After Receiving Your Deposit
Color
as Color Card or Customer Requirement
Advantage
Thermal Insulation, Waterproof, Fireproof
Transport Package
Export Fine Packaging
Specification
950/980/1000/1130/1150*6000 mm
Trademark
OEM
Origin
China
HS Code
73089000
Production Capacity
10000m2/Day

Product Description

Sandwich Panel Sandwich Board For Roofing or Wall

Insulated Sandwich Panel Wall Panel Roof PanelRock wool is made from basalt as an important material, which is melted at high temperature and then made into man-made inorganic fibres by high-speed centrifugal equipment, together with special binder and dust-proof oil, and then cured by heating to make various specifications.
Product Parameter
Product name Polyurethane Edge Rock Wool
Steel Thickness 0.4-0.7
Surface Pattern Small Pipple,Middle Groove,Pure Flat
Effective Coverage 400-1000mm
Recommended Coating Fluorocarbon Coating Pvdf,Smp Coating,Hdf Coating,Polyester Pe Coating,Etc
Stock Color White Gray,Silver,Sea Blue,Etc.
Core Thickness 50,75,100,Etc.
Core Material Name Polyurethane Polyurethane Edge Glass Wool Polyurethane Edge Rock Wool
Thermal Conductivity 0.019-0.024w/m.k 0.035-0.041w/m.k 0.035-0.041w/m.k

Insulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof PanelSandwich plate application range is very wide
A cold room or freezer
Vegetable and fruit storage room
Logistics facilities, cold storage
Production and office buildings, workshops
Service station, hangarInsulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof Panel
Insulated Sandwich Panel Wall Panel Roof PanelInsulated Sandwich Panel Wall Panel Roof PanelShandong Xirui Metal Materials Co., Ltd established in the old plant area on March 1, 2007, with business mainly including steel structure maintenance system, production and processing of new and energy saving building materials, color plates, sandwich panels, color steel profiled board, houses in form of containers, K-type mobile houses and villa houses maintenance materials, as well as integrated house products.

As a leader in steel structure and color steel industry in China, Xirui Group has always been committed to research on energy conservation, environmental protection, ecological construction, to promote green energy-saving building materials and new steel structures as our responsibility, and has now formed an industry chain closely connected with production and marketing of core products such as steel structure and enclosure plates, engineering design, construction and installation of steel structure, international trade, environmental protection, energy-saving and heat insulation materials.

Based on its own advantages and strengths in terms of geographical location, and the marketing strategy of "Explore International Market as well as Domestic Market", Xirui Group has been striving to expand its international market, follow international norms, obtain self-support import and export rights, and conduct external construction, design, consulting and project management. It has obtained USA FM certification, Russia GOST certification and established good international business channel relations with the Ministry of Commerce, the United Nations International Trade Department, the Russian Far East, with Southeast Asian countries such as Sri Lanka, Indonesia, Thailand and Maldives, with African countries such as Sudan, Angola, Benin, Niger, Zambia, Nigeria, Congo, Ghana, Guinea, Senegal, Kenya, Tanzania, Burkina Faso, and Uganda, with West Asia Countries such as Pakistan, Afghanistan and Kazakhstan, and established good cooperation with Russia and Mongolia. Its products have been widely exported to these countries. Major overseas projects undertaken in recent years include: Russian Market, Russia Birobidzhan Iron Mine, Vladivostok Shopping Mall, Bush grain store, Bush logistics warehouse, Russia Cement Plant, Russian Chemical Plant Rotary Furnace Project, Zhengbang Far East Pulp Mill, Mongolia Suzuki 4S Shop, Mongolia GOBI Woollen Sweater Factory, Heidelberg Cement Plant in Indonesia, Nigeria Cement Plant, Zambia Economic Park Steel Structure Plant and Maldives Membrane Structure.Insulated Sandwich Panel Wall Panel Roof Panel
Insulated Sandwich Panel Wall Panel Roof Panel
FAQ


Q1. Are you a factory or a trading company?
We are a professional factory with ISO, and CE standards, and OEM service is welcome.

Q2. What's your delivery time?
The salesman will confirm the time accordingly, large orders should communicate with the order management department in advance. Normally,delivery time is 5-15 days after receiving the deposit. Large order delivery time should be arranged separately.

Q3. How to control the quality of your product?
a) Quality of the design: think about possible problems in advance and provide a high-quality design solution.
b) Quality of the raw material: choose the qualified raw material
c) Quality of the production: precise manufacturing technique, experienced workers, strict quality inspection.

Q4.what length can you offer?
The sandwich panel is transported by 20'GP or 40'HQ. So in order to take good advantage of container space, we suggest a length of no more than 11.8 M.

Q5.How long time your paint will last?
The durable time will be different in different zinc and paint coating. Also, different environment has different effect on the durable time.
