Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage

Looking for high-speed rapid roll-up doors for cold storage? Our factory offers industrial automatic thermal insulated PVC fabric roller shutter doors. Get the best quality for your cold storage needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
YO-Freezer
Type
Rolling
Open Style
Rolling
Opening Type
Induced
Special Function
Thermal Insulated
Color
Red/Blue/Yellow/Green/Gray/Ornage/Transparent
Certification
ISO9001, CE
Position
Industrial
Surface Finishing
Finished
Power Supply
1-Phase 220V, or 3-Phase 380V
Steel Structure
304 Stainles Steel or Powder Coated Gi
PVC Fabric Panel Thickness
20mm
Installation Area
Interior
Working Temperature
-35 to 65 Celsius Degree
Transport Package
Export Wooden Box
Specification
Max size 3m*4.5m
Trademark
YUOU
Origin
China
HS Code
85308000
Production Capacity
5000pieces/Year

Packaging & Delivery

Package Size
300.00cm * 50.00cm * 80.00cm
Package Gross Weight
400.000kg

Product Description

Description
Cold storage rapid door widely used in food, chemical, textile, electronics, supermarket, cold storage, logistics, warehousing and other production efficiency, dust-free and high temperature level requirements.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
Technical data:
220 V Freezer Room Insulated Keep Temperature Cold Storage Door
Max dimension
width * height 3500mm*4000mm
Power supply
220±10%V, 50/60Hz. Output power 0.75-1.5KW
Normal speed
open1.2m/s close 0.6m/s
Max speed
open 2.0m/s close 1.0m/s
Opening frequency
1000 times /day
Wind resistance
28m/s (Class 10)
Air tightness
leakage through the door is 95m³/hour under 30 pa pressure

Structure Diagram:
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
Product Details:

1. PVC Fabric:
Insulated PVC sandwich fabric: double skin is 0.8mm PVC fabric, and inside is filled with high-denisity insulating rock wool, total thickness is 20mm.

Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
2. Zipper Design:
Use zipper to connect the fabric with frame side guide rail as a whole body, realizing better sealing performance and air-tightness. And when there is accident collision, the fabric can get out from guide rail and return automatically, this reduces daily maintance.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
3. Anti-Freezing Heating Design:
All-round heating wire belts are used to avoid freezing of door structure. This can avoid demage for fabric and driving system when the door is frozen steadily in low temperature room.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
4. Frame and Rails:
Two guide rails, which includes one top cover and one motor cover included.
Thickness:1.5mm for guide rail,1.0mm for cover box.
Standard material: Galvanized steel,surface is painted.
Optional material: 304 stainless steel or aluminum alloy.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
5. Motor and Controller:
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
6. Colors:Blue\Yellow\Orange\Grey\White\Full clear\Green
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
5. Safety devices(Below three devices are included as standard):
A.Safety photo cell sensorWhen there is human or vehicle under the door,the door will stop closing and get up automatically.Thiswill avoid accident collisions.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
B.Safety bottom airbag sensor
When the bottom bar of the door touches something,it will stop closing immediately and get up automatically.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
C.Alarm light and emergency buttons
The lamp flashing to warn passing human or vehicles.And buttons on both side.
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
6. Operation methods:

Vehicle loop detector,Radar sensor,Push button,Pull switch,Remote control

Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
You will receive:
 Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
Products real shot:
Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold StorageIndustrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage

Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage Industrial Automatic Thermal Insulated PVC Fabric Freezer Room High Speed Overhead Rolling Rapid Roll up Fast Acting Roller Shutter Doors for Cold Storage
