Electric Folding Ladder for Caravan with CE Certificate

Looking for an Electric Folding Ladder for Caravan with CE Certificate? Look no further! We are a factory that specializes in producing high-quality, reliable caravan accessories.
Request a Quote


Basic Info.

Model NO.
Platform Size
Warning Sign and Sound
LED and LED Cover
Transport Package
Wooden or Carton Box
CE certificate
Jiangsu. China
HS Code
Production Capacity

Product Description

Ø  Operation
This folding electric step is controlled by motor.
This folding electric step is operated by means of a design switch which combines perfectly with the modern motor home.
Ø  Construction
All folding electric steps have aluminum frames. The step is made of anodized aluminum with safe rounded edges. For most of the steps, the side plates are in anodized aluminum as well.
All steps are continuously tested. Maximum loading capacity is 200kg.
Ø  Safety
A switch for connection to a warning light in the vehicle is supplied as standard.
For safety, the folding contraction electric step edges are rounded and equipped with yellow sticker at front adge.
All steps have equipped with anti-slip foot boards as standard.
For safety in the dark, this step equips with a set of LED's as standard.

The folding contraction electric step slide-out can be mounted onto several types of vans by using our special mounting kits:
1.      Sliding side door and cab hinged doors
2.      Cars, minibuses, taxi
3.      Adapted vehicles for disabled vehicles
4.      Ambulances and accessible vehicles
5.      Motor caravans and campers
Ø  Extremely solid and very light weight
Ø  Attention to safety
Ø  Attractive design
Ø  Loading capacity can be 200 kg
Ø  Equipped with anti-skip platform

4.Technical Function
Ø  Voltage: 12V or 24V
Ø  Max current during extending or stowing under normal situation: 14-16 A
Ø  Extending time: 1-2 s
Ø  Stowing time: 1-2 s
Ø  Test weight: 250 kg
Ø  Safety grade:IP67
Ø  Safety loading capacity: 200 kg
Ø  Noise: the noise of the step is below 70dB when working.

5. Safety Function
Ø  The platform surface is the aluminum board with the function of anti-skid
Ø  There are sound signal for warning during step working
Ø  If the platform touches an obstruction when extending out, it will return back. Then the operator should press the switch again to extend the platform. That function is still available.
Ø  This step and the vehicle door are interlocked.
